Continuous Epidural/Peridural Anesthesia Kit, G18 Catheter, Intrafix Primeline Closed System Infusion Set

The continuous epidural/peridural anesthesia kit with G18 catheter is equipped with the Intrafix Primeline infusion system and supports gravity and pressure infusion administration. The set contains sterile, latex-free components with luer-lock catheter compatibility and labeling compliant with the Medical Device Directive requirements.

The infusion system operates as a closed system, featuring a drip chamber with an integrated filter that prevents the release of chemical substances, vapors, and liquids into the surrounding environment. The PrimeStop cap within the Intrafix Primeline product group maintains closed system integrity in accordance with the NIOSH 2004 definition during use and drainage when the instructions for use are followed.

Technical characteristics:
• IV infusion set suitable for gravity and pressure infusion up to 2 bar
• Dual-body drip chamber with rigid transparent upper section and flexible lower section
• Drop former calibrated at 20 drops ≅ 1 ml
• Integrated 15 µm filter in the drip chamber
• Manual air vent with 0.2 µm antibacterial filter and protective cap
• Infusion tubing diameter 3 mm x 4.1 mm and length 150 cm
• Flow regulator with V-shaped groove for precise low flow rate adjustment
• Tubing fixation and parking element
• Plastic spike for bottle insertion with dual ports
• Luer-lock catheter connection
• EO sterilized
• Latex-free construction

Instructions for use: the system is defined as a closed system according to NIOSH 2004, as the integrated filter prevents the release of contaminants into the adjacent environment during the drainage phase, provided that puncturing and priming are performed according to the instructions and the air vent is closed during covering.

The product is technically designed for controlled infusion administration in continuous epidural or peridural anesthesia procedures in medical settings.
